2. Overview

2.1 Pack Contents

• Parent Unit x 1
• Baby Unit (Camera) x 1 (x2 in Max View 2 camera model)
• AC Power Adapter x 2 (x3 in Max View 2 camera model)
• Wall mounting screw set x 1 (x2 in Max View 2 camera model)
• User Manual x 1
2.2 Parent Unit Overview
1. Power ON/OFF/SLEEP Button
2. Charging LED
3. Power LED
4. Volume Level LEDs
5. Volume Up/Down Buttons
6. MENU/EXIT Button
7. Night Light
8. Menu Navigation Keys; Pan & Tilt Navigation Keys
9. OK/ZOOM Button
6
10. Camera Switch Button
11. Split Screen Button
12. Talk Back Button
13. Microphone
14. Speaker
15. Antenna
16. Reset Hole (Under the Antenna)
17. Stand
18. Charging Port
2.3 Baby Unit Overview
19. Infrared LEDs
20. Lens
21. Light Sensor (Night Vision)
22. Power LED
23. Microphone
24. Speaker
25. Night Light
26. Temperature Sensor
27. ON/OFF Switch
28. Charging Port
29. PAIR Button (On the Bottom)

3. Getting Started

3.1 Powering the Baby Unit (Camera)
• Connect the Camera Power Adapter to the Charging Port (28) on the back bottom of the Baby Unit.
• Plug the AC power adapter into the wall outlet.
• Ensure the ON/OFF switch (27) is in the ON position.
• The unit will power on automatically and the green power LED (22) will light up.
• Use the ON/OFF switch (27) to turn the Baby Unit off.
Only use the AC power adapter included in this package.
