1� mounting with screws:
a) Transfer the mounting points of the mounting plate to the vehicle roof and drill the
corresponding holes�
b) Fix the mounting plate securely on the roof�
c) Use standard body sealant to seal the mounting screws�
d) Fasten the Dish support so that the satellite dish lies horizontally when retracted�
2� assembly additionally with adhesive:
a) If possible, transfer the outline of the mounting plate to the vehicle roof when scre-
wed on for fixing�
b) After loosening the screws, clean the area marked and the mounting plate�
c) Slightly roughen the substrate and apply the mounting adhesive evenly�
d) Press the system evenly onto the mounting surface�
e) Then screw the antenna back on�
f) Observe the drying time of the adhesive used�
g) Use commercially available body sealant to seal the mounting screws�
h) Remove any excess adhesive�
3� mounting the cable gland:
Control cable (antenna)
YSL - J8 x 0,5 mm
2
Cable gland
3
1
Antenna cable (LNB)
a) Transfer the outline of the cable gland to the vehicle roof�
b) Drill the appropriate holes for the cable entry into the vehicle interior�
c) Seal the cable gland�
d) Glue the cable gland to the vehicle roof with suitable mounting adhesive�
Control cable (control unit)
YSL - J8 x 0,5 mm
Seal
F-Plug
Antenna cable (control unit)
