Product overview
1
7
6
8
1 Nozzle
2 Trigger feed
3 Handle
4 Mains cable
Operation
• Put a glue stick (Ø7 mm) into the trigger feed. Press the trigger to advance the glue stick into
the trigger feed.
• Connect the mains plug to a standard mains socket. The product starts to heat up immediately.
• Let the product heat up for 5 minutes.
• Press the trigger to make the liquid adhesive exit the nozzle.
• Unplug the mains cable from the household power outlet after use.
Do not pull the glue stick out of the product. The remaining glue stick can remain in
the product once you have finished working.
Tips for glueing
• The bonding surfaces must be free of dust and grease, and dry. Do not use flammable
detergents and solvents.
• Zigzag lines of glue are good for glueing flexible materials (e.g. textiles).
Beads of glue are good for glueing all other materials.
• Press the trigger carefully and apply the adhesive to the parts to be glued. These parts can
be glued together within 15-20 seconds. If necessary, insert new glue sticks into the product.
• The bonding time is approximately 30 seconds and about 90 % of adhesion occurs after one
minute. The bonding time for thick beads of glue can be longer or shorter for small ones.
• Do not glue large areas at once, but work in sections. Apply the adhesive in a corrugated
pattern.
• You can increase adhesion by preheating the surfaces to be glued together, e.g. with a hot
air gun.
• Only remove adhesive residue when cold.
• You can loosen or adjust glued areas by heating them, e.g. with a hot air gun.
• If you wish to glue two different materials together, first apply adhesive to the harder material.
• The liquid adhesive can fill small holes and cracks.
2
3
4
5
5 Mains plug
6 Trigger
7 Stand
8 Glue sticks
Troubleshooting
Problem
The product does not turn on.
The adhesive is not liquid enough.
Care and cleaning
• Always disconnect the product from the power supply before cleaning it.
• Let the product cool down completely.
• Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these may
damage the casing or cause the product to malfunction.
• Use a dry, lint-free cloth to clean the product.
Disposal
This symbol must appear on any electrical and electronic equipment placed on the
EU market. This symbol indicates that this device should not be disposed of as
unsorted municipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose
of it separately from unsorted municipal waste. Spent batteries and accumulators,
which are not enclosed by the WEEE, as well as lamps that can be removed from
the WEEE in a non-destructive manner, must be removed by end users from the
WEEE in a non-destructive manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back
of waste. Conrad provides the following return options free of charge (more details on our
website):
• in our Conrad offices
• at the Conrad collection points
• at the collection points of public waste management authorities or the collection points set up
by manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in
countries outside of Germany.
Technical data
Operating voltage ......................... 220 – 240 V/AC, 50 Hz
Power consumption ...................... 10 W (operation), 30 W (heating)
Heating-up time ............................ 5 min
Melting temperature ...................... 170 °C
Cable length ................................. 1.4 m
Operating/storage conditions ........ 0 to +35 °C, 20 – 99 % RH
Dimensions (L x W x H) ................ 115 x 29 x 120 mm
Weight .......................................... 163 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming, or the capture in
electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.
This publication represents the technical status at the time of printing.
Copyright 2025 by Conrad Electronic SE.
Possible cause and solution
Check to see if the plug is properly
connected to the wall outlet.
The mains cable or plug is defective.
Please contact the manufacturer.
The heating-up phase was too short. Let
the product heat up longer.
*1553630_v2_0525_02_dh_mh_en
