Man & Machine Its Cool Flat Wireless Bedienungsanleitung

Operating Manual • Bedienungsanleitung • Mode d'emploi • Manual de usuario
• Manual do usuário • Istruzioni d'uso • Gebruikshandleiding • Installation • Instrukcja obsługi
A
USB
D
5
E
1 4
G
F
5
5
Part functions:
EN
1
USB-C port: Used to connect charging cable. Cover using the
USB-C Port Cover during washing or rinsing.
2
Battery charging cable: Used to charge keyboard battery.
USB-C Port Cover: Used to cover USB-C port during washing or
3
cleaning.
4
POWER switch
5
Pairing keys: 'ESC' and 'M' keys for RF; 'BLANK' and 'F2' keys for BT
pairing.
6
LED indicator: RED: keyboard battery is charging; Blinking
GREEN: keyboard is attempting to pair to USB Dongle (7); Solid
GREEN: keyboard is paired to USB Dongle (7) and connected to
the computer; Blinking BLUE: keyboard is attempting to pair via
Bluetooth™; Solid BLUE: keyboard is paired and connected to the
computer via Bluetooth™.
7 USB Dongle: Used when using RF connection method to transmit
keyboard RF signal to the computer. Located on bottom of the
keyboard.
Power ON/OFF:
Slide the POWER (4) switch to the ON or OFF position to turn the keyboard ON or
OFF.
Switching Between Modes:
Man & Machine Its Cool Flat Wireless supports both Bluetooth™ mode and RF
mode. Use the mode commands outlined below to switch between Bluetooth™
and RF connection.
7
1
BT
6
Its Cool (replacement) Drape
(See figures A and B)
6
B
4
7
5
RF
5
Pairing Instructions:
If using Bluetooth™ mode, select the appropriate Bluetooth™ version during
pairing. If using RF mode, ensure the USB dongle is properly connected to the
computer. Follow the Quick Reference Table below for detailed pairing
instructions.
Note: To pair the keyboard in Bluetooth™ or RF mode, it must first be set to the
corresponding mode before beginning the pairing process.
Quick Reference Table:
Function
Power ON/OFF
Switch to Bluetooth
Mode
Switch to RF (dongle)
Mode
Pair to another
dongle (RF mode)
Pair with Bluetooth
(3.0 or 5.0)
Note: The keyboard is already paired with the USB dongle that comes with it. If
you are using this keyboard in combination with the Man & Machine C Mouse
Wireless, you can use one USB Dongle to operate both devices. Once you have
installed the first device with its dongle, connect the other device to the same
Before first installation, fully charge
the battery using a 5V/1A USB charging
device and the included USB-C cable.
1
2.4 GHz
2
C
Action
Slide the POWER (4) switch to the ON or OFF
position
Press [BLANK] key + F2 simultaneously (5) →
TM
BLUE LED (6) will turn ON → BLUE light will flash
slowly while trying to acquire a known BT device
Press [BLANK] key + F1 simultaneously (5) →
GREEN LED (6) will turn ON → GREEN light will
flash slowly while trying to acquire a known RF
dongle
Press ESC + M keys simultaneously (5) → GREEN
LED (6) will blink fast (20 sec) → Hold keyboard
near the dongle → Unplug & reinsert the dongle
to complete pairing
Press [BLANK] key + F2 simultaneously (5) for 3
TM seconds → BLUE LED (6) will blink fast (120 sec)
→ Hold keyboard near BT device → Select
version (3.0 or 5.0)
BT
3
3
