Components - Panels
Please check you have all the panels listed below
1
Rail x 1
315x100x6mm
Drawer Base Panel x 1
4
456x270x3mm
7
Left Side Panel x 1
725x330x35mm
Base Panel x 1
10
470x330x35mm
13
Right Hand Door x 1
282x234x15mm
2
Drawer Side Panels x 2
280x70x9mm
Drawer Front x 1
5
470x70x15mm
8
Right Side Panelx 1
725x330x35mm
11
Basket x 1
14
Left Hand Door x 1
282x234x15mm
-3-
3
Drawer Back Panel x 1
447x70x9mm
6 Top Panel x 1
600x360x15mm
9
Center Panel x 1
470x330x35mm
12
Back Panel x 1
480x387x3mm
