Costway MU10094DE Bedienungsanleitung Seite 2

• External ports on the rear panel
II. Performance Preparation
● Installing batteries
The instrument requires the use of six 1.5V "AA" batteries.
Open the battery compartment cover on the backside and
load in the batteries one by one with correct polarity. Replace
the cover when the compartment is fully loaded. (Batteries is
not included)
*Energy or voltage dissipation will result in the loss of
volume and timbre distortion. Discharged or bad batteries
MUST be replaced immediately to ensure the effect of
performance. Always remove the batteries when you are not
using the product for a long time.
04
● Power adaptor
A dedicated power adapter shall be used. Connect the output end of the adaptor to the
power port on the rear of the keyboard, and then the other end to the power socket.
(Note: the input voltage of the adaptor shall be compatible with the power supply
voltage)
● Audio output / external headphone
◆ Audio output: Firstly, turn off the keyboard and the external audio devices, secondly,
connect one end of the audio cable to the PHONES/OUTPUT port on the rear panel of
the keyboard, and then connect the other end to the audio input port of the audio
devices.
◆ Headphone connection: When connecting a headphone to the PHONES/OUTPUT
port on the back of the keyboard, the loudspeaker will be disenabled automatically. In
this way, you can perform without disturbing others.
※ Note! When using a headphone, do not turn up and keep the volume to the
maximum for a long time, which may cause hearing loss.
● Mic Input
◆ Mic input: Connect a microphone (not included) to the MIC port to sing while playing
the keyboard.
III. Basic Performing Method
Press [ POWER ON/OFF] button, and the LED display will turn on and show the
current tempo "120". Then you may play the Keyboard as required.
● Master volume adjustment
Press [ MASTER VOL +] or [ MASTER VOL -] to increase or decrease the overall
volume. Press [MASTER VOL+] and [ MASTER VOL –] simultaneously to reset to the
default value.
The master volume can also control the accompaniment volume.
● Accompaniment volume adjustment
Press [ACCOM VOL +] or [ACCOM VOL -] to increase or decrease the accompaniment
volume. Press [ACCOM VOL +] and [ACCOM VOL -] simultaneously to reset to the
default value.
05
