4. Proper use
The product is only suitable for charging smartphones,
tablets and power banks.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator,
not the manufacturer, is responsible for damages or
injuries of any type resulting from this. An element of
the intended use is also the observance of the safety
instructions, as well as the assembly instructions and
operating information in the operating manual. Persons
who operate and maintain the product must be familiar
with the manual and must be informed about potential
dangers. In addition, the applicable accident preven-
tion regulations must be strictly observed.
Other general occupational health and safety-related
rules and regulations must be observed. The liability of
the manufacturer and resulting damages are excluded
in the event of modifications of the product.
The product may only be operated with original parts
and original accessories from the manufacturer. The
safety, operating and maintenance specifications of the
manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with
the intention of use for commercial or industrial purpos-
es. We assume no guarantee if the product is used in
commercial or industrial applications, or for equivalent
work.
5. Safety instructions
General safety instructions
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Please read through the safety instructions carefully
before use.
• Do not use the product if you notice any damage or
irregularities.
• Protect the product against moisture and water.
• Avoid contact of the module surface with pointed or
sharp-edged objects.
• You should not loosen the pre-assembled electrical
cables to the charge controller.
• Use only original or certified USB charging cables.
16 | GB
Warning! This product generates an electromagnetic
field during operation. This field can impair active or
passive medical implants under certain circumstances.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of the
medical implant prior to operating the product.
6. Technical data
Dimensions in folded condition
Dimensions in unfolded
condition
Dimensions of the cells
Nominal power
Max. operating power (lmpp)
Max. supply voltage (Vmpp)
No-load voltage (Voc)
Short circuit current (lsc)
Protection category
Efficiency of the solar cells
Operating temperature
Output voltage of the charge
controller
Output current of the charge
controller
Cell type
Weight
Note: The rated power is tested under standard test
conditions: 1000 W/m
Subject to technical changes!
7. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
www.scheppach.com
370 x 415 x 40 mm
1765 x 415 x 10
155 x 120 mm
100 W ± 5
5.5 A (±0.2)
22.3 V~
21.5% ± 0.2%
-40°C - +80°C
17V~(±0.5)
3.9 A (±0.2)
Monocrystalline
, 1.5 AM, 25°C.
2
mm
18V~
7.2 A
IPX4
3.2 kg
