SD Card Reader/USB Port: For using external media on this device, just plug your
1.
SD/USB into these ports.
LED Screen: All information regarding external media or this device will be
2.
displayed from this screen.
Folder and track selection: Press this knob to enter Folder control, Press again to cancel.
3.
Master Volume Knob: Adjust the master volume. Press this Knob to select EQ.
4.
Power Switch: Press this Switch to turn the unit on and o .
5.
MICROPHONE INPUTS: For connecting KARAOKE or EXTERNAL MIC.
6.
Microphone Volume Control Knob: Turn this knob to adjust the microphone
7.
volume level.
Microphone Delay time Control Knob: Turn this knob to adjust the microphone
8.
delay time.
Microphone Reverb Depth Control Knob: Turn this knob to adjust the microphone
9.
Reverb Depth.
Bass Control: Turn this knob to adjust the low frequencies of LCH and R CH.
10.
11. Treble Control: Turn this knob to adjust the high frequencies of L CH and R CH.
Balance: Control the volume balance from left Chanel to right Chanel.
12.
Headphone Output Jack: Connect the Headphone.
13.
14. Input Selector: Turn this button to choose the favorable input.
AUX Input: IPOD/MP3 JACK-IPOD/MP3 connects to this jack.
15.
AUDIO INPUT: Connect the audio output jacks of DVD/CD to these jacks.
16.
17. LINE OUTPUT: Connect the RECORD input jacks to these jacks.
Optical Input: Connect the Optical Output Jack frorn TV, DVD etc.
18.
Coaxial Input: Connect the Coaxial Output Jack from TV, DVD etc.
19.
20. HD 1 Input: Connect the HD Output Jack from TV, DVD etc.
HD 2 Input: Connect the HD Output Jack from TV, DVD etc.
21.
HD Output: Connect the HD Input Jack to TV, Monitor etc.
22.
23. SPEAKER OUTPUT: Connect your speaker system to these terminals.
FM ANTENNA CONNECTOR: Connect for FM antennas.
24.
BLUETOOTH ANTENNA: Pull the antenna out when using Bluetooth input
25.
26. POWER SUPPLY: Connect to AC 115V/60Hz and 230V/50Hz outlet.
POWER VOLTAGE SELECTOR: 115V/230V.
27.
