14. Tighten both screws at the swivel joint and place the swivel joint in recess 05.
15. Place the X-module in recess 06.
16. Loosen the screw connecting the YZ connector to the Z-module.
17. Pull off the YZ connector with Y-module. The YZ connector remains at the
Y-module.
18. Tighten the screws at the YZ connector.
19. Place the Y-module with YZ connector in recess 04.
20. Loosen the screw connecting the Z-module holder to the Z-module and pull off
the Z-module.
21. Tighten the screw of the Z-module holder (in the scope of the microscope
adapter).
22. Place the Z-module in recess 03.
23. Insert the lid padding.
24. Place the tool bag in recess 02.
25. Close the box and send it to the authorized service.
10.2 Transportation and short-term storage limits
Air temperature
-40 °C – 60 °C
For long-term storage, the device should be stored in accordance with the ambient
conditions of the working area, see chapter 9.3.
10.3 Contact details
10.3.1 Legal Manufacturer
Biozol Diagnostica Vertrieb GmbH
Oehleckerring 11–13
22419 Hamburg
Germany
www.cmi.calibrescientific.com
10.3.2 Local Calibre Scientific distributor
www.cmi.calibrescientific.com/en/contact
TransferMan
Relative humidity
10 % – 95 %
