ENGLISH
Specific Conditions of Use
EN
1. Not more than one single or multiple strand lead shall be connected
DE
to either side of the terminals, unless the conductors have been
joined in a suitable manner, e.g two conductors into a single insulated
FR
boot lace ferrule.
IT 2. Leads connected to the terminals shall be insulated suitable for 255V
and this insulation shall extend to 1mm of the terminal throat.
RU
3. All terminal screws, used and unused, shall be tightened to between
0,5 and 0,7 Nm.
PL
4. The temperature at sensor bulb shall not exceed 585°C.
PT
5. The temperature at the cable gland shall not exceed 60°C.
6. The minimum bend radius is 6 times the diameter of the sensor.
ET
7. T he minimum installation temperature of the sensor is −50°C.
8. The sensor gland must be tightened to a torque of 8 Nm.
Sensor:
Type:
Material:
Temperature measuring range:
Maximum exposure temperature:
Length:
Maximum operating power:
Enclosure:
Temperature range:
Protection class:
Terminals:
Cable glands:
Installation and commissioning guidelines:
When the sensor is used as part of a SIL2 Safety Temperature
Limiter installation:
• Perform a resistance measurement and calibration of the measuring
circuit as part of the commissioning procedure. This to ensure the
proper working of the PT100 sensor.
• Confirm the proper working of the nVent RAYCHEM MONI-PT100-EXE
(-AMB) sensor by comparing the measured temperature with the real
pipe temperature as part of commission procedure.
• Make a visual inspection of the product installation during pre
installation check. Check that the RTD wiring and shielding are
connected correctly.
• When the sensor is connected to the electrical heat-tracing cable
make sure that the fixture is correct and permanent.
Location of the MONI-PT100-EXE sensor
• Away from valves, flanges, supports, pumps or other heat sinks.
• At the top of the pipe for thermally sensitive pipe contents (A).
• On lower quadrant of pipe 90° for single heating cable (B).
• On lower quadrant of pipe centrally between the heating cables if
they are two or more (C).
Attachment of the MONI-PT100-EXE sensor
• Fix sensor firmly on surface with adequate fixing tape in two places (D).
• Fix sensor parallel to the pipe (D).
• Route extension cable to avoid damage. Fix to pipe with tape.
|
4 nVent.com/RAYCHEM
PT100, 3 wire. DIN IEC 751, Class B.
Stainless steel tip. Stainless steel
connection cable.
–100°C ... +500°C
+585°C
2 m
0,15 W
−50°C ... +60°C
IP 66
for 0.5 to 1.5 mm cable
2
M20 (connection cable, 10–14 mm)
