2 PACKAGE CONTENTS
1
4
9
1
MULTIMEDIA SYSTEM
1A
ADAPTER
2
POWER WIRING HARNESS
3
CAN BUS INTERFACE STEERING WHEEL
CONTROLS supplied already connected to
POWER WIRING HARNESS 2
4
RCA OUTPUT WIRING A
RCA - FR
RCA - FL
AUX IN R
AUX IN L
SUB-WOOFER
AUX VIDEO IN 1
FRONT CAMERA
MIC
AMP
1A
5
6
10
12
11
5
6
7
8
9
10
11
12
13
9
3
2
8
RCA OUTPUT WIRING B
WI-FI ANTENNA
PARKING
CAMERA
FAN
RCA OUTPUT WIRING C
RCA - RR
RCA - RL
CAN-TX/CAN-RX
AM/FM ANTENNA
DAB+ ANTENNA
GPS ANTENNA
USB 4 PIN CABLE
USB 6 PIN CABLE
MICROPHONE AND FIXING ACCESSORIES
INSTRUCTION MANUAL
EN SM348
