SOMFY Amy 4 Modes io Anleitung Seite 15

Amy 4 Modes io
3.6.Tips and advice on use
3.6.1.Questions about the product?
Observations
The selected motorised product does not react
at all when a button on Amy 4 Modes io is
pressed (No LED reaction when pressing the
buttons).
The selected motorised product does not react
at all when a button on Amy 4 Modes io is
pressed (No LED reaction in the front when
pressing a button AND in the back when pressing
the On/Off button).
The selected motorised product does not react
at all when a button on Amy 4 Modes io is
pressed but the LED lights up.
The selected motorised product does not react
at all when a button on Amy 4 Modes io is
pressed but the LED lights up and the control
point is paired with this motorised product.
Only one button of the channel selector can be
selected.
The selected motorised product does not react
as it should.
All the LEDs of the channel selection buttons
flash rapidly (6 times).
NOTICE
If the product still does not operate, contact a drive and home automation professional.
3.6.2.Replacing a broken or lost Somfy control point
To replace the last broken or lost control point, contact a home motorisation and automation professional.
4.TECHNICAL DATA
Frequency range and maximum power used: 868.700 MHz - 869.200 MHz e.r.p. <25 mW.
The environment in which the product is used might reduce the radio range. The use in the same floor as the controlled
products is recommended. Radio range in free field: .
Operating temperature: 0 °C (+32 °F) to +48 °C (+118.4 °F).
Power supply: 1 x type CR2032 battery, 3 V.
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Possible causes
Amy 4 Modes io is switched off, the
front panel buttons (Up, Stop/my,
Down) are deactivated.
The control point battery is low.
The control point is not paired with
this motorised product.
External radio equipment is
interfering with the radio reception.
Amy 4 Modes io is switched off, the
channel selector is active but only
one channel can be selected at a
time.
The selected mode does not match
the type of motorised product.
The ergonomics used on Amy 4
Modes io are only possible by
selecting only one channel.
No channel is selected.
Solutions
Switch it on to activate the buttons
(refer to Switching on Amy 4
Modes io).
Change control point battery as
required (refer to Replacing the
battery).
Refer to Adding/Deleting Amy 4
Modes io
Turn off any nearby radio
equipment.
Refer to Channel selection.
Refer to Mode selection.
Select one channel at a time and
repeat the procedure to carry out
the order on all the channels.
Select at least one channel before
sending an order.
EN
15
