Maintenance

Field Lens Maintenance
If laser power a enuation occurs, for example, engraved pa erns are
shallow or uneven, the Field Lens may get dirty. Clean it with the lint-free
cloth moistened with alcohol.
Dust Filter Cleaning
Remove the cover on the left side of the Laser Unit to clean the dust filter if
there is dust buildup.
*The filter on the right side of the Laser unit is an air intake filter and cannot be removed.
14
Conical Protective Cover Exhaust Fan Cleaning
If smoke runs out of the protective cover, the exhaust fan and smoke outlet
may be blocked due to dust. Unscrew the fan from the cover using a
screwdriver and clean them to ensure proper smoke exhausting.
Laser Unit Leveling
It is recommended to level the Laser Unit before use. If it is not level, the
Laser Unit can be adjusted to a level state by using the H2 hex key to adjust
the two leveling screws on the cantilever arm.
( Hex Key H2 )
