Definitions
1. Starter Grip
2. Rear Handle
3. Throttle
Lockout
4. Throttle Trigger
5. Blocking Lever
6. Filter Box Cover
7. Manual Fuel Pump
8. Spark Plug Boot
9. Front Handle
10.Carburetor Adjusting
Screws
11.Starting Throttle Lock
12.Stop Switch
13.Fuel Filer Cap
14.Fuel Tank
15.Muffler
16.Fan Housing
17.Choke Lever
18.Blade Scabbard
19.Cutting Blade Guard
20.Cutting Blades
The grip of the pull starter,for starting the
engine.
The support handle for the hand， located at or
toward the rear of the hedge trimmer.
Trigger Must be depressed before the throttle trigger
can be activated.
Controls the speed of the engine.
Lever for rotating the rear handle.
Covers the air filter.
Provides additional fuel feed for a cold start.
Connects the spark plug with the ignition lead.
Handlebar for the hand at front of hedge
trimmer.
For tuning the carburetor.
Keeps the throttle partially open during starting.
Switches the engine's ignition off and stops the
engine.
For closing the fuel tank
For fuel and oil mixture.
Reduces engine exhaust noises and diverts
exhaust gases away from operator.
Polymer housing which encloses the power
unit.
Eases engine starting by enriching mixture.
Covers cutter blades when hedge trimmer is
not in use.
Helps to reduce the risk of operator contact by
the cutter blade.
Steel blades for cutting hedges and shrubs.
