Cleaning And Maintenance; Environmental Protection; Warranty Limitations - Kidwell Rollo Benutzerhandbuch

MOUNTING REAR WHEELS
1. Turn the ride-on toy's body (A) upside-down and place the rear wheel axle (C) in
the dedicated holes. Then place the locking plugs (D) on the axle ends and push
them into the holes in the body. The axle should be able to rotate freely, but with no
possibility of sliding out of the body.
2. On the ends of the axle, place the following in the order of their appearance:
• rear wheel (G) – 1 pc.
• nut (E) – 1 pc.
and carefully tighten both nuts (E) at the same time, using 10 mm open-end wrench
(H).
3. Fit, apply and tighten wheel plugs X (J) – 2 pcs. – per to Fig. 3.
DISASSEMBLY OF HANDLEBAR AND FRONT WHEELS
1. From the underside of the ride-on toy's body (A), place the bar with the front wheels
(B) in the dedicated hole.
2. From the top of the ride-on toy's body (A), slide the handlebar bar (L) into the top of
the bar with the front wheels (B).
3. Tighten the outer handlebar nut (L) carefully, using the supplied socket wrench (F).
Afterwards, fit, apply and tighten the steering wheel plug (I).
4. Fit, apply and tighten wheel plugs X (J) – 2 pieces and wheel plugs Y (K) – 2 pcs.

CLEANING AND MAINTENANCE

1. Clean the ride-on toy with a damp cloth using a solution of water and soap.
2. Do not use hard brushes or sharp-edged objects to clean this product.
3. Do not clean with aggressive chemicals.
4. Each time before using the ride-on toy, make sure that all screws are tightened
properly.
5. Use a silicone-based lubricant for moving parts. Use it only when necessary.
6. If there is excess lubricant, remove it from the product with a clean cloth.
7. To avoid friction between moving parts, which may cause damage to the ride-on toy,
make sure that such parts are clean and there is no dirt, sand or dust in them.
8. When the product is not used, it should be stored in a dry room, at normal temperature.
9. If it is necessary to replace individual elements, use original spare parts or parts
authorised by the manufacturer.
10. When used frequently, the adjustment parts wear down slowly. When they lose their
properties, replace them as soon as possible.
11. Disassembly the ride-on toy by following the assembly steps in reverse order.

ENVIRONMENTAL PROTECTION

When you discontinue using this product, have it disposed at a proper waste management
facility according to the local laws to protect the environment.

WARRANTY LIMITATIONS

The product warranty does not cover failure or loss of any parts caused by the product
falling down, scuffing, incorrect assembly, or use against the manual.
10
