F R O N T PA N E L
1. Power button
2. Power LED
3. SATA LED
4. WiFi LED
5. Memory card reader (SD/SDHC/SDXC)
6. Headphone/Audio Out jack
7. Microphone jack
8. USB 3.1 port
9. Thunderbolt 4 port
R E A R PA N E L
1. WiFi antenna connector
2. LAN (RJ45) ports
3. USB 3.1 ports
4. USB 2.0 port
5. DisplayPort
6. HDMI port
7. Power input (DC19V)
S E T T I N G U P YO U R ZOTAC Z B OX N A N O
1. Connecting antenna for Wi-Fi
2. Connecting to a wired home network
3. Connecting USB 3.1 devices
4. Connecting USB 2.0 devices
5. Connecting a DisplayPort display
6. Connecting an HDMI display
7. Connecting the power adapter and turning on
the system
