8.4.7.7 ALU-S2
• Applies to truck/car
ALU-S2 function permits balancing wheels with light alloy rims by fitting two adhesive weights: one on the outer and one on inner sides of the rim (the inner
weight is at "12 o'clock"). Enter the measurements (see paragraph 8.4.2.1 "Programs rapid setting and measurements through distance-diameter caliper
arm" or 8.4.6.1 "Manual setting of wheel dimensions") and proceed with the balancing operations.
At the end of the procedure, the wheel balancing conditions can be checked by performing a trial spin.
The procedure has now been completed.
8.4.7.8 ALU-1
• Applies to car
ALU-1 function permits balancing wheels with light alloy rims by fitting adhesive weights on the outer and inner sides of the rim at "12 o'clock". Enter the
measurements (see paragraph 8.4.2.1 "Programs rapid setting and measurements through distance-diameter caliper arm" or 8.4.6.1 "Manual setting of
wheel dimensions") and proceed with the balancing operations.
At the end of the procedure, the wheel balancing conditions can be checked by performing a trial spin.
The procedure has now been completed.
EN_128 1301-M004-01
SCREEN WHEEL BALANCER
Fig. 142
Fig. 143
