Authorized KICKER Dealer:
Purchase Date:
PERFORMANCE
Woofer Size
Tweeter Size
Frequency Response
Max Amplifi er Power
Sensitivity [1W/1m]
Nominal Impedance
Weight
Mounting Hole Diameter
Mounting Depth
2 PS5250
Ω 2006–present
4 PS52504
Ω 1998–2005
2008–present Victory
Please refer to your bike's factory service manual for dissassembly/installation information. Typically, you should
retain all factory screws, hardware, and grilles when upgrading your bike to a KICKER system. The following
diagrams show how to install the PS5250 speakers in a Harley-Davidson bike with "batwing" style fairing (2006–
present). Note: Do not install in systems that are not 2-ohm stable!
1. Remove front side of fairing.
1
2
2 0 1 0 P S 5 2 5 0 4 R e v A . i n d d 2 0 1 0 P S 5 2 5 0 4 R e v A . i n d d 2 0 1 0 P S 5 2 5 0 4 R e v A . i n d d 2 0 1 0 P S 5 2 5 0 4 R e v A . i n d d 2 0 1 0 P S 5 2 5 0 4 R e v A . i n d d 2 2 2 2 2
PS COAXIAL SPEAKERS
Owner's Manual
5-1/4" [133mm]
3/4" [20mm]
60Hz–20kHz
100W PEAK | 50W RMS
88.3dB
2 (PS5250), 4 (PS52504)
Ω Ω
12.6oz [358g]
4-7/8" [124mm]
2-3/16" [56mm]
Harley-Davidson® with premium audio system and similar touring bikes
Harley-Davidson with premium audio system [
Davidson parts 77021-98B and 77022-98B
2
3
PS COAXIALS
2 3 / 1 6 "
5 6 m m
4 7 / 8 "
1 2 4 m m
Road Glide may require Harley-
]
7 x Torx T25
4
5
9 / 1 6 "
1 4 m m
6
7
