Notes:
•
If your receiver/ampli er has more than one set of speaker terminal (A and
B),connect only one or the other to the controlcenter.
•
For the best results, we recommend 14-gauge, two conductor speaker wire
(not supplied) for most connections. If you plan to locate the speakers further
than 80 feet from the control center, use a heavier gauge of wire.
OPERATION
Caution: To avoid damaging your receiver/ampli er, set the volume to the
lowest setting before changing the control center's settings.
To turn on a pair of speakers connected to the control center, simply press in
the desired button. For example, to turn on the set of speakers connected to
SPK A, press A.
To turn o a pair of speakers, press the button again so it is in the "out" position.
Note: if no speakers are connected to a set of terminals, do not press in the
corresponding control button.
IMPEDANCE CHART
Impedance is a measurement of the load placed on your receiver/ampli er by
the speakers. The load placed on your receiver/ampli er from the control center
will vary depending on how many pairs of speakers you turn on at one time,
and on which speakers you turned on. The chart below shows the impedance
for all possible combinations of 8-ohm speakers.
Speaker Sets On
A, B, C or D
A+B, A+C, A+D
B+C, B+D, C+D
A+B+C, A+B+D
A+C+D, B+C+D
A+B+C+D
Impedance ( )
8
4
3.1
2.4
