TECHNICAL DATA
to use with
Max. Signal range
Battery lifetime - normal use
Battery lifetime - stand by
Power supply
Frequency range
Max. transmission power
Antenna gain
Type of protection
Ambient working temperature
Storage temperature
WARNING! Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference.
PRODUKT DESCRIPTION
A Bluetooth Remote Controller. The unit consist of a remote unit
housing and a rubber band to fit the remote to the vacuum cleaner
bend-end/hose or any power tools. The function of the remote unit
is to control a Milwaukee vacuum cleaner by wireless control. The
remote control has a build-in sensor that can detect when a vibrating
power tool is connected to the hose/tool adapter and is being turned
on/off, thereby it is possible to control the vacuum cleaner by using
the "AutoSense" feature to activate/deactivate the vacuum. This
product is for professional use only. Any other application is non-
intended use.
Installation instruction:
This device is stand-alone handheld radio equipment, not for
installation.
Setup & Indication Lights:
Please read the "Quick Guide" located in the products cardboard box.
A vacuum cleaner and Remote can only be connected one to one.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
WARNING!This device contains a button-type/coin cell
lithium battery. A new or used battery can cause severe
internal burns and lead to death in as little as 2 hours if swallowed or if
it enters the body. Always secure the cover on the battery
compartment. If it does not close securely, stop the device, remove
the battery and keep it out of reach of children. If you believe that
someone has swallowed the battery or that it has otherwise entered
the body, seek immediate medical attention.
How to remove battery:
Remove back battery cover by turning it counterclockwise with a
suitable tool, like a coin. Turn the Remote around so the battery falls
out.
How to deal with leaking batteries:
If leaking batteries are discovered in the product the batteries
must be removed at once to minimize damage to the product. It is
recommended to use plastic gloves when handling leaking batteries.
The contents of leaking batteries can cause chemical burns and
respiratory irritation. If exposed to the contents of a leaking battery,
please wash with soap and water. If irritation persists, please seek
medical attention. In case of eye contact, please flush eyes thoroughly
with water for 15 minutes and seek medical attention.
2023_10_25 4931425975_AS2-250EM_250EH_2-1.indd 7
2023_10_25 4931425975_AS2-250EM_250EH_2-1.indd 7
REMOTE CONTROL
AS2-250EM / AS2-250EH
20 m
> 1 year
> 2 years
3 V ⎓ / CR2032
2402-2480 MHz
+2,5 dBm
4,91 dBi
IP44
-10 °C ... 40 °C
-30 °C ... 70 °C
ENGLISH
ENGLISH
SPECIFIED CONDITIONS OF USE
To be used only to switch vacuum cleaners on and off remotely.
Do not use this product in any other way as mentioned above.
RESIDUAL RISK
Even when the product is used as prescribed, it is still impossible
to completely eliminate certain residual risk factors. The following
hazards may arise in use and the operator should pay special
attention to avoid the following:
• Injury caused by vibration. Hold the product by designated
handles and restrict working time and exposure.
• Exposure to noise can cause hearing injury. Wear ear protection
and limit exposure.
• Injury due to flying debris. Wear eye protection, heavy long
trousers, gloves and substancial footwear at all times.
• Inhalation of toxic dusts.
WORKING INSTRUCTIONS
Disconnect after use.
OPERATION
LED 1
Manual On/Off
LED 1:
Blue, flashing
Pairing in progress
Blue , illuminated
Pairing successful
5 seconds
Green
Pushing any button when Remote and
vacuum cleaner is connected
Red
Pushing any button when Remote and
vacuum cleaner is not connected
Yellow, flashing
Low Battery mode (<10 %) Replace
battery
LED 2:
Green, flashing (2x)
Reconnected to vacuum cleaner
Red, flashing
Low airflow warning
LED 3:
Green, flashing
AutoSense is on and Remote and
vacuum
cleaner is connected
CLEANING
For cleaning we recommend using a wet cloth with a mild detergent
added and to finish with a light rinse with cold water from a running
faucet.
MAINTENANCE
Use only Milwaukee accessories and Milwaukee spare parts. Should
components need to be replaced which have not been described,
please contact one of our Milwaukee service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at: Techtronic
Industries GmbH, Max-Eyth-Straße 10, 71364 Winnenden, Germany.
EC-DECLARATION OF CONFORMITY
Hereby, Techtronic Industries GmbH declares that the radio
equipment type "Remote Control" are in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: http://services.
milwaukeetool.eu.
LED 2
LED 3
AutoSense mode
7
