1 – Introduction
iCart Prophy is a dental cart specifically designed to support NSK's equipment such as Varios Combi Pro.
It includes bracket on the rear of the column to rest the power supply cord, and to avoid any unexpected
movement during use, the front wheels are fitted with brakes.
Upon receipt, you will find
•
Basis equipped with wheels (1)
•
Adjustable column, equipped with mounting screws (2)
•
Shelf for medical device (3)
•
Set of screws for shelf and hex key for assembly (4)
2 - Operating manual
2.1 Assembly instruction
In order to assemble the cart, proceed as follows:
•
Insert the screws located on bottom of the column through the corresponding opening of the
base plate
•
Slide the column as illustrated below and tighten the screws to secure it
•
Attach the shelf to the upper part of the mast using the countersunk screws
Step 1
Be careful not to fix the shelf upside down.
p. 2
Step 2
RD 160.iCart P.OPM.ENG.V1 11.04.2021
Step 3
