• Always wait until the machine has come to
a complete stop before placing it down. The tool
insert can jam and lead to loss of control over
the power tool.

2. MACHINE INFORMATION

Intended use
The machine is intended for sawing wood, plastic
and metal while keeping the baseplate resting
firmly on the workpiece. It is suitable for straight
and curved cuts. It is also possible to cut flush to
the workpiece surface. A suitable saw blade must
always be used.
Technical specifications
Model No.
Rated voltage
No load speed
Saw stroke
Max. saw capacity wood
Max. saw capacity steel
Weight
Sound pressure level LPA
Sound power level LWA
the front handle:
vibration cutting wooden beam a
vibration cutting board a :
h,B
the rear handle:
vibration cutting wooden beam a
vibration cutting board a :
h,B
Only use the following batteries of the AX-POWER
20V battery platform. Using any other batteries
could cause serious injury or damage the tool.
CDA1158 20V, 1.5Ah Lithium-Ion
CDA1154 20V, 2Ah Lithium-Ion
CDA1155 20V, 4Ah Lithium-Ion
The following charger of the can be used to
charge these batteries.
CDA1156 / CDA1184 Charger adapter
CDA1157 / CDA1175 Quick charger
The batteries of the AX-POWER 20V battery
platform are interchangeable with all the FERM
AX-POWER battery platform tools.
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with
a standardized test given in EN62841; it may be
RSM1024
20 V
0-3200/min
25mm
115mm
10mm
1.7 kg
93.7 dB(A), K=5dB(A)
101.7 dB(A), K=5dB(A)
: 14.832m/s 2 , K=1.5 m/s 2
h,WB
2 2
16.228 m/s , K=1.5 m/s
2 2
: 12.824 m/s , K=1.5 m/s
h,WB
13.054 m/s 2 , K=1.5 m/s 2
used to compare one tool with another and as
a preliminary assessment of exposure to vibration
when using the tool for the applications mentioned.
• Using the tool for different applications, or with
different or poorly maintained accessories,
may significantly increase the exposure level.
• The times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
1. Lock-off button
2. On/Off button
3. Handle
4. Battery (not included)
5. Battery unlock button
6. Auxiliary handle
7. Baseplate
8. Chuck
9. Clamping lever
3. ASSEMBLY
Before any work on the power tool,
remove the battery.
The battery must be charged before first
use.
Inserting the battery into the machine
(Fig. A, F)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (4) into the base of the
machine as shown in Fig. F.
2. Push the battery further forward until it clicks
into place.
