ETHERMA EZ-3600, 230V~ / 400V3N~ are intended
for permanent installation by an authorized electrician
and in accordance with existing national regulations.
The appliance must be preceded by an all-pole
switch, min. 3mm contact gap.
Appliance and protection class: Class I - IP44.
1. The EEZ can be mounted to the ceiling or on the
wall, horizontally, where the lowest installation height
is 1.8m (2.3m UK) from the floor level. Respect and
follow the minimum distances to the surrounding sur-
faces, according to fig.1. If the heater is fitted in verti-
cal position the connection box must be positioned at
the lower end of a sloping ceiling. Fixed heater must
not be mounted in front of a socket outlet.
2. The two supplied ceiling brackets should be fitted
with a C/C distance, see fig.2 and table. There are
two mounting holes per ceiling bracket, where "D"
is the distance between the holes, fig.3. The fixing
brackets "FB", on top of the heater, is to be hung up
and fixed to the ceiling brackets.
3. We recommend fitting on to the ceiling or similar,
on supplied ceiling brackets, due to the width. If
the heater must be suspended with chains or wire
please use hanger for EEZ-3600 (optional extra).
4. On top of the heater there are two cable grommets
"CG", fig.2, allowing multiple connections. Connection
according to fig.4a, 4b or 4c to a 16mm² terminal
block. When using connection 4b, one heating
element at a time can be connected (for three output
steps). Protect the supply cable, if it comes in contact
with hot parts!
5. When starting-up the heater for the first time or
after a long period of disuse, smoke or odor may
result from grease, dust or dirt that has collected on
the element. This is normal and disappears after a
short period of time. Ensure that the room/space is
well ventilated during this process.
6. Like in all electrical heating appliances, clicks can
occur during expansion and contraction of the material,
due to movement when the temperature changes.
7. The heater may undergo a color variation (bronz-
ing effect) following being energized for the first time
and during its life span. The extent is relevant to the
operating environment and is normal behavior.
Aerosols, paint, solvents, dust and filth etc... may
adhere to the heater and can potentially cause discol-
oration. The performance of the heater is unaffected
by discoloration or bronzing. As a precaution, always
switch off the heater while painting and drying!
8. If refit is needed, the heating elements and/or the
alu-panels can be replaced in site without having to
take down the heater. Unscrew lid and wires. Pull or
push the part in question and replace with a new one.
9. Information about energy consumption
In combination with an Ecodesign-compliant
thermostat, the product data complies with the EU
regulations on the Ecodesign Directive (2009/125/
EC) for energy-related products (ErP).
10. Safety
• When the installation is protected by an RCD, a
300mA residual current device has to be used.
• Warning - Hot surface! Do not touch the heater
when in use!
• Do not cover the heater! Risk of fire!
• This appliance shall not be used by children less
than 8 years or persons with reduced physical,
sensorial or mental disability or lack of experience
and knowledge, unless they are supervised or
were instructed how to use the appliance in a
safe way, and understand the hazards involved.
Children shall not play with the appliance. Clean-
ing and user maintenance shall not be made by
children without supervision.
ErP
