ASSEMBLY INSTRUCTION
Hang the electronic dartboard in a location where you have at least 3 meters of clearance for throwing. The Bulls
Eye, the center of the board, should be positioned 1.73 meters above the ground to achieve the official tournament
height. To mount the board at the correct height, mark a point on the wall using the center hole of the Easy-Fix wall
bracket at a height of 173 cm from the ground. Then, mark and drill the positions for the four holes. Next, screw
the Easy-Fix wall bracket onto the wall using four screws until the bracket is securely attached. Ensure that the wall
bracket is level during installation. Afterward, the CB-Smart can be easily hooked into the bracket from above. If the
bracket is slightly crooked, it can be adjusted using the integrated locking system by gently turning it.
POWER CONNECTION
The electronic soft dartboard CB Smart is powered by a USB- cable. Insert the cable into the socket on the dartboard,
and plug the power adapter with a USB- port into the power outlet (not included). You can also operate the device
with 3 AA batteries (not included). When using batteries, do not mix old and new batteries, and do not use alkaline,
carbon zinc batteries, and rechargeable nickel-cadmium batteries simultaneously.
12
Dartboard
Device dimensions:
Height:: 45 cm
Width:
Depth:
173 cm from the ground
to the middle of Bull's Eye
237 cm
8180.01 Karella Dartautomat CB Smart
41,5 cm
7 cm
Oche line
