ORIGINAL INSTRUCTION MANUAL
RETAIN FOR FUTURE REFERENCE
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS AND CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE
FOR THEPURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE
FOR FUTURE USE
1.SAFETY INSTRUCTIONS
1.1 GENERAL SAFETY
Ensure Health & Safety, local authority, and general
WARNING!
workshop practice regulations are adhered to when using this
tool.
Familiarize yourself with the specific applications
WARNING!
and limitations of the kit, as well as any potential hazards.
This kit should be used in conjunction with inspection
maintenance procedures recommended in the vehicle
manufacturer's manual.
Ensure that the kit is correct for the task.
Wear the appropriate personal protective equipment for the
task. A full range is available from your Sealey dealer
use the kit for any purpose other than that for which it
DO NOT
is designed.
Ensure that the vehicle is properly supported with axle stands
before working under the vehicle.
Ensure there is adequate lighting prior to using the kit. A range
of inspection lamps are available from your Sealey dealer.
Keep children and unauthorized persons away from the working
area.
use the kit if any parts are damaged or missing, as this
DO NOT
may cause failure and/or personal injury.
use the kit when you are tired, or under the influence of
DO NOT
alcohol, drugs or intoxicating medication.
After use, store in a safe, dry childproof area.
The force screw maximum recommended torque is 170Nm (M18x1.5), 155Nm (M16X1.5), 99Nm (M14X1.5), 60Nm (M12X1.5),
33Nm (M10X1.5).
Exceeding these torque values may shorten the life of the force screws. The force screws are considered to be consumable
items and areNOT covered under warranty.
2 INSTRUCTION
Comprehensive kit for fast and effective in-situ removal/installation of wheel bearings/suspension bushes and
seals.
Reduces the possibility of damaging the bearing/suspension housings. Supplied with twenty two adapters from
44 to90mm and five force screws in carry case. Adapters can also be used in a standard workshop press when
in situ access isn't possible.
TecTake GmbH
Tauberweg 41, D-97999 lgersheim, Germany
INSTRUCTION MANUAL
1
ALWAYS KEEP FORCE SCREW
WELL LUBRICATED.
MOLYBDENUM/COPPER BASED
GREASERECOMMENDED.
DO NOT USE
AIR TOOLS
401104
Fig.1
