Your rollator is equipped with various components, you should know these
components and parts before proceeding to read this user manual. Design and
specifications could be changed without further notices.
SPECIFICATION
Overall width: 64cm
Overall depth: 67cm
Seat area: 45.5*25cm
Adjustable handle height: 79.5-92 cm
Max. user weight :136 kg
Net weight: 8.8 kg
1. Remove the rollator from the packing and remove the protective foils. The
rollator will be folded as shown in Figure 1.
1
2
4
5
9
8
6
11
2
1. Handle
2. Adjustable parking/running brake
3. Backrest
4. Seat area
5. Height adjustable spring button
6. Shock absorbing spring
7. Bag
8. Brake adjustment
9. Rear wheels
10.Front wheels
11.Cane holder
Figure 1
