Atlas Copco SDS Produktanweisungen Seite 10

Product Instructions
Product Instructions
Technical data
Technical data
Rated voltage
Rated input
Rated current
Construction class
Size
Weight
Range of applicable screw sizes
Max screw length
Hopper capacity
Applicability of special screw types
Useful information
Log in to Atlas Copco www.atlascopco.com
You can find information concerning our products, accessories, spare parts and
published matters on our website.
Ergonomic guidelines
Consider your workstation as you read through this list of general ergonomic
guidelines and see if you can identify areas for improvement in posture, compo-
nent placement, or work environment.
• Take frequent breaks and change work positions frequently.
• Adapt the workstation area to your needs and the work task.
• Adjust for convenient reach range by determining where parts or tools
should be located to avoid static load.
• Use workstation equipment such as tables and chairs appropriate for the
work task.
• Avoid work positions above shoulder level or with static holding during as-
sembly operations.
• When working above shoulder level, reduce the load on the static mus-
cles by reducing the weight of the tool, using for example torque arms,
hose reels or weight balancers. You can also reduce the load on the static
muscles by holding the tool close to the body.
• Make sure to take frequent breaks.
10
EN
100/240 VAC – 50/60 Hz
15 VDC
800 mA
Class 1
182(W) x 126(L) x 147(H) mm
2.2 kg (excl. power supply)
11 sizes between M1 and M5
(1.0 mm, 1.2 mm, 1.4 mm, 1.7 mm, 2.0 mm, 2.3 mm,
2.6 mm, 3.0 mm, 3.5 mm, 4.0 mm, 5.0 mm)
Up to 19 mm (excl. head length)
200 - 220 cm
Screw length vs. thread diameter 1:1
Thickness of screw head 0.2 mm
© Atlas Copco Industrial Technique AB - 9836 794200 00
