EN
10
Location of mains input
Undo the screws and remove the panel covering the cable entry point on the HPP.
Run a correctly sized piece of power cable through the cable entry point shown in the view below.
Connect the power cable to the terminals behind the panel then replace the panel and secure it with
the screws.
Undo the screws
HPP 6, 8, 12 and 15
Cable Entry point
These terminals for connecting
the HPP to the power supply
are behind this panel.
HPP 6, 8, 12 and 15
L
N
P1 P2
HPP 20
