Your new PCM20A Stereo Power Ampli er
gives you the power and versatility that you need in a professional sound
system. The wide frequency response is perfect for the ampli cation of vocals
and music. The talkover function for the Mic 1 and Aux Input located on the front
panel make it perfect meeting halls, auditoriums, sports events, schools and
o ce paging systems. Great for anywhere you need to deliver a special
announcement with excellent sound quality.
FEATURES AND CONTROLS
FRONT PANEL
1
1. Power ON/OFF and Indicator: Main power switch, the indicator lights when
the ampli er is turned ON
2. MIC 1 and MIC 2/AUX Volume Controls: Adjust the output signal level of the
corresponding inputs.
3. BASS and TREBLE Tone Controls: Adjust the bass and treble of the
corresponding output signals.
4. MODE, PLAY, PREV and NEXT Function Control buttons:
• MODE Button: For audio selection like WIRELESS BT/SD/LINE IN
• PLAY/PAUSE BUTTON: Play and Pause control button
• PREV/NEXT: Quick backward or next song
5. LED Display
6. SD/MMC Socket for playing SD/MMC cards
7. USB Charge Port: USB port for smartphone charging only, no USB reader
function
8. AUX Input: To connect the high impedance audio source such as Tape Deck,
CD player, or Tuner with 1/4" plug via audio plug adapter (two phono RCA
plugs into 1/4" mono jack).
4
5
2
6
7
3
www.PyleUSA.com
9
8
5
