RTK Wall Mount Installation
1
Screw Selection and Installation
• Expansion Screws (for concrete or slate walls and similar surfaces)
1� Mark the spots of screw holes on the wall mount, then use an impact
drill to create 4 holes,12mm (0�47") diameter and 50mm (1�97") deep�
12x50mm
2� Remove the expansion screw nuts and insert their shafts into the
pre-drilled holes�
3� Position the wall mount in alignment with the 4 screw shafts for
proper seating�
4� Thread the nuts onto the screw shafts to secure the wall mount�
6
EN
• Wood screws (for wooden walls and similar surfaces)
Place the wall mount close to the wall and thread the screws with an
impact drill to ensure stable anchoring�
