Parts Overview

Expansion Screw *4
RTK Wall Mount *1
Note:
The RTK Pole Assembly Screw and the Allen Key can be obtained in
the contents of the ECOVACS GOAT package.
4
EN
Wood Screw *4
Allen Key *1
RTK Pole Assembly Screw *1

Location Selection

1 Location Setting Criterion
Select a location that is solid, level, and free from obstructions�
Recommended installation sites for the RTK Reference Station are
elevated areas, such as walls and roofs, devoid of obstructions and
shading�
2
Signal Testing
Charge the RTK Reference Station and place it in the intended
installation location to verify its signal via its indicator lights� A solid blue
light indicates a suitable location with reliable signal strength, whereas a
flashing light requires Station relocation to achieve optimal positioning�
(Wait 1 minute following power-on before observing indicator light
conditions�)
