swing2sleep Gestell Montageanleitung Seite 5

Stick an anti-slip pad on each adjustable foot. Then screw one
2.
adjustable foot firmly into the threads.
4x
1
Now turn the bracket parts over and place them on the feet. Next, take the
firmly connected brackets and turn them vertically upwards so that the
3.
brackets are facing upwards with the opening. The caps must now be pla-
ced on the tube openings on the lower brackets (depending on the frame,
these may already be in place). The grub screws on the underside must
now be tightened again using the Hex key
4.
3
2
5.
4
Next, the middle tubes are attached to the
brackets using the plug-in system.
1x
click
Important:
sound Listen for the „click" sound and make sure
that the locking clip is visible.
7.
6.
Now you can put the Top bracket on top.
Important:
Tighten the star knob as far as it will go.
Use the lock nut underneath the bracket
to also tighten it firmly
