Turn the thermostat clockwise to set the desired temperature. Set the appliance to the maximum (+)
position first. The indicator light turns on when the room temperature is lower than the temperature
selected on the thermostat. The appliance heats up and oscillates if this mode has been selected. When
the room temperature is higher than the selected temperature, the appliance stops, the indicator light
goes off and the appliance does not oscillate anymore.
As soon as the room temperature is ok, slowly reduce the thermostat until the indicator light goes out.
This appliance is Ideal to heat a surface of 20 m².
NOTE: To avoid power circuit overload situation, it is recommended that no other appliances are
operating at the same time from the power outlet it is plugged into.
Overheat protection
The heater is fitted with a safety device which will switch off the heater in case of accidental overheating
(eg. Obstruction of air intake and outlet grilles, motor turning slowly or not at all) . To reset, disconnect the
plug from the power for approximately 10 minutes, remove the cause of overheating then plug the
appliance in again.
Cleaning and maintenance
Before cleaning always turn off the appliance, unplug it and let the appliance to cool down.
To remove dust from the appliance use dry cloth or vacuum cleaner.
Table
Model identifier for electric local space heaters
Model
DOM477
number:
Item
Heat output
Nominal heat out-put
Minimum heat output
(indicative)
Maximum continuous
heat output
Auxiliary electricity consumption
At nominal heat output
At minimum heat output
In standby mode
Type of heat input, for electric storage local space heaters only (single select)
manual heat charge control, with integrated thermostat
manual heat charge control with room and/or outdoor
temperature feedback
electronic heat charge control with room and/or outdoor
temperature feedback
Symbol
P
1.8
nom
P
1.1
min
P
1.8
max,c
el
N/A
max
el
N/A
min
el
0
SB
www.livoo.fr
Value
Unit
kW
kW
kW
kW
kW
kW
Yes
No
Yes
No
Yes
No
