Great Plains Industries, Inc.
5252 E. 36th St. N.
Wichita, KS 67220
Tel: 800-835-0113
Direct:316-686-7361
Fax: 316-686-6746
Email:
gpisales@gplains.com
Specifications
Inner Diameter
Design Type
Fitting
Accuracy
Repeatability
Flow Range
Operating Temperature
Reads
Display
Wetted Materials
Powered By
Pressure Rating
To Use With
Do Not Use With
Model
Approvals
Warranty
Item # 113700-02, 01A Red Turbine Methanol Meter
This meter is specifically designed for use with methanol. This aluminum turbine meter displays gallons and
includes 1 in. NPT threads. Flowrate is 3 to 30 GPM (10 to 100 LPM). Field replaceable AAA batteries.
Ready to Buy? Find a GPI Distributor in your area!
1 in.
Turbine
NPT
±5.0 % of reading
±0.5 %
3 to 30 GPM
10 to 100 LPM
+14 to 130 ºF
-10 to 54 ºC
Gallons or Litres
LCD
4 Digits
Aluminum with Nickel Plating Housing
Ceramic Bearings
Tungsten Carbide Shaft
Nylon Rotor
Ferrite Signal Generators
316 Stainless Steel Rings
Two alkaline AAA Batteries (average 5-year use)
21 bar
300 PSI
Diesel fuel (biodiesel blends B20)
Gasoline (alcohol blends E15)
Kerosene
Methanol
Water or chemicals
01A31GM Methanol
CE
2 years
4/4/2019 | Page 1 of 1
