4 • UDR116
SPECIFICATIONS
Receiver
Power supply ................................................................................................................ 15-18Vdc / 350mA
S/N ratio........................................................................................................................................... >105dB
Sensitivity ......................................................................................................................................... -105dB
Range ........................................................................................................................................... 120m max
Frequency response ............................................................................................................. 40Hz - 18kHz
Output level: ......................................................................... 0-400mV balanced, 0-200mV unbalanced
Dimensions ..................................................................................................................... 200 x 44 x 171mm
Weight of the set ................................................................................................................................ 1.3kg
Microphone
Frequency band............................................................................................................. UHF 863-865MHz
Max. RF output............................................................................................................................. -6.85dBm
Display ................................................................................................................................................... LCD
Power supply ...........................................................................................................2 x AA 1.5V batteries
Battery life time ....................................................................................................................................... 8h
