EN
2
Dimensions
Order-No.
DN
7110006500
65
7110000800
80
Flange connection dimensions to DIN EN 1092-3
Flange
PN 16
DN 65
Flange
PN 25
DN 80
8 /24 – K410071100001-00 / 06.2024 – © www.kemper-group.com
Dimensions
D1
D2
D3
(mm)
(mm)
(mm)
(mm)
185
118
65
236
200
132
80
237
Hole Ø mm
Bolt hole Ø mm
145
Hole Ø mm
Bolt hole Ø mm
160
H1
H2
L1
S1
(mm)
(mm)
(mm)
89
290
20
97
310
22
Number of holes
18
4
Number of holes
18
8
SW1
SW2
kvs
kg
(mm)
(mm)
12
24
33
19,71
12
24
43
21,20
Nominal size
M16
Nominal size
M16
