LENCO PA-101BK Bedienungsanleitung Seite 5

1. PREV: Press this key to go to the previous track in USB/BT mode.
2. VOLUME -: To decrease the levels.
►ǁ/TWS: Press to play/pause a track.
3.
Press and hold to TWS (true wireless stereo) mode on or off.
4. STANDBY/LIGHT: Press and hold to Standby ON or OFF. Press to change the light mode between
LED1,LED2,LED3,LED4,OFF.
5. SOURCE: Press to change the source between USB, BT, LINE
6. MENU:Press this key to change the menu between MIC/GUITAR VOLUME, ECHO VOLUME,BASS,
TREBLE, X.BASS, White flashing lamp.
" mean for MIC/GUITER VOL 10, press "-/+" to adjust 0-30.
Display "
" mean for ECHO VOL 10, press "-/+" to adjust 0-30.
Display "
" mean for BASS 00, press "-/+" to adjust ± 6 dB.
Display "
" mean for TREBLE 00, press "-/+" to adjust ± 6 dB.
Display "
" mean for X.BASS on, press "-/+" to on or off.
Display "
" mean for White flashing lamp on, press "-/+" to on or off.
Display "
7. VOLUME +: To increase the levels.
8. NEXT: Press this key to go to the next track in USB/BT mode.
9. LED DISPLAY: Display speaker status.
10. LINE IN: Line input socket
11. USB: USB input socket
Important: The USB port is intended only for data transfer only, other devices cannot be used with this
USB connection. The use of USB extension cords is not recommended.
12. AC INPUT: AC 100-240V,50/60Hz.
POWER SWITCH: Switch power between ON or OFF.
13.
14. MIC: Wired microphone input socket
15. GUITAR: Guitar input socket
STA ND BY
SOU RCE
LIGHT
ME N U
5
PANEL
