Acer LCD Monitor Quick Start Guide (QSG)
Important safety instructions
Please read the following instructions carefully.
1.
To clean the LCD monitor screen:
•
•
Spray a non-solvent cleaning solution onto a rag and clean the screen gently.
2.
Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely damage
it.
3.
Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display.
4.
Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform servicing of
any nature.
5.
Store the LCD monitor in a room with a temperature of -20° to 60° C (-4° to140° F). Storing the LCD monitor outside
this range may result in permanent damage.
6.
Immediately unplug your monitor and call an authorized technician if any of the following circumstances occur:
•
Monitor-to-PC signal cable is frayed or damaged.
•
Liquid spills onto the LCD monitor or the monitor is exposed to rain.
•
The LCD monitor or case is damaged.
Attaching the monitor to the base
1.
Remove the monitor from the packaging.
2.
Remove the screws of the base for use, align the neck with the base,and tighten the screws.
3.
Clip the bracket into the notch of the rear housing in sequence and press it down. Hear a "click" and the installation
is completed.
Connecting your monitor to a computer
1.
Turn off your computer and unplug your computer's power cord.
2.
Connect the signal cable to the HDMI (optional) and /or DP (optional)
and /or Type C (optional) input socket of the monitor, and the HDMI (optional)
and /or DP (optional) and /or Type C (optional) output socket of the graphics
card on the computer.
3.
USB Type C Cable (Optional, USB Type C input models only) Connect one
end of the USB type C cable (optional) to your computer and connect the
other end to your electric devices.
4.
Connect the USB Cable(Optional)
Connect the Type-C cable to port for fast charge.
Connect the USB 2.0/USB-B cable to port.
5.
Insert the monitor power cable into the power port at the back of the monitor.
6.
Plug the power cords of your computer and your monitor into a nearby electrical
outlet.
7.
Connecting HDMI/DP+USB-B to computer 1 and USB-C to computer 2 when Control
up to 2 computers from a single set of keyboard and mouse connected to the monitor.
Note: Audio output is only for audio output model. Please check user
manual for more instruction.
Transmitting the 4K 160Hz signal via one DP 1.4 port .
If your computer USB-C do not have DP-Alt, pls connect HDMI/
DP+USB-B to computer 1 and HDMI/DP+USB-C to computer 2.
AMD FreeSync Premium:
It can allow a AMD FreeSync Premium supported graphics source to dynamically adjust display refresh rate based on
typical content frame rates for power efficient, virtually stutter free and low-latency display update.
KVM switch:
The built-in KVM switch allows you to control up to 2 computers from a single set of keyboard and mouse connected to the
monitor.
USB Type C
USB
DP
HDMI(2.0)
DP IN
Type-C
USB-B
USB
USB
AUDIO OUT
USB
AC IN
