Safety advices:
Installation and repairs to the equipment may only be carried out by
technicians observing the current VDE guidelines. No liability will be
assumed in the case of faulty installation and commissioning.
Before opening the equipment pull out the power plug or remove the
power supply, otherwise there is danger of electrocution. This is also
valid for cleaning the equipment or working on the connections.
Only use the mains cable connected to the device. Never replace any
parts or make any modifications on the mains cable. Otherwise there is a
risk of mortal injury for which we cannot be held liable.
Providing that a serviceable fuse exists, the power plug must be pulled
out before changing the fuse. Defective fuses may only be replaced with
standard compliant fuses that have the same nominal value.
The equipment may only be operated in dry rooms. In humid rooms or
outdoors there is danger of short-circuit (caution: risk of fire) or
electrocution.
To prevent damage to your equipment and to avoid possible peripheral
damages, the devices foreseen for wall mounting may only be installed
on a flat surface.
Choose the location of installation or mounting so that the power plug
can be reached and pulled out of the socket easily in case of danger.
Choose the location of installation or mounting such that children may
not play unsupervised near the equipment and its connections. The
location of installation or mounting must allow a safe installation of all
cables connected. The mains cable as well as feeder lines may not be
damaged or clamped by objects of any kind.
Choose the location of installation or mounting so that under no
circumstances liquids or objects can get into the equipment (e.g.
condensation, water coming from leaking roofs or flowing water, etc.).
Avoid exposure of the equipment to direct sunlight and to other heat
sources (e. g. radiators. other electrical devices, chimney, etc.). Devices
that are equipped with heat sinks or ventilation slots must under no
circum-stances be covered or blocked. Also ensure for a generous air
circulation around the equipment. In this way you avoid possible damage
to the equipment as well as a risk of fire caused by overheating.
Absolutely avoid that cables come near any source of heat (e.g.
radioators, other electrical devices, chimney, etc.).
State of the art 2019-12-09
Technical improvements, changes in design, printing- and other errors expected.
All manuals and user guides at all-guides.com
Technical data:
Type
Inputs
Number
Frequency range
250...2350 MHz @ SAT
Level (AGC)
Isolation V | H.
Subscriber ports
Number
Supported standards
Tap loss TERR
Frequency range (SAT)
User bands
Gain SAT Unicable II (SCR/CSS)
Gain SAT (Legacy)
Output level SAT (SCR/CSS)
Trunk outputs
Number
Through loss TERR
Through loss SAT
Connectors
Connector type
General
Current consumption
Equipotential bonding connection
Dimensions (W × H × D) appr.
Protection class
External accessories
Switching power supply
100...240 VAC / 50...60 Hz | 19 VDC/940 mA
Power inserter
5...2400 MHz | 18V/750 mA
Herewith AXING AG declares that the marked products comply with the valid
guidelines.
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
Manufacturer
EEA contact address
AXING AG
Bechler GmbH
Gewerbehaus Moskau
Am Rebberg 44
8262 Ramsen
78239 Rielasingen
SES553219
5
5...862 MHz @ TERR
SES 5532-19
59...94 dBµV
>25 dB
premium-line
2
EN 50494, EN 50607
Programmable
13 dB
950...2150 MHz
32
Unicable II Multiswitch
25 dB
10 dB
84 dBµV
Quick start guide
5
3 dB
3 dB
F
500 mA
4 mm²
195 × 145 × 85 mm
IP 20
