INSTRUCTION MANUAL
InLine® SATA 6Gb/s Controller with 4 SATA Ports PCI-Express 2.0
GENERAL INFORMATION
Validity:
These operating manual applies to the following products:
• 76617E InLine® SATA 6Gb/s Controller with 4 SATA Ports PCI-Express 2.0
Manufacturer:
INTOS ELECTRONIC AG
Siemensstraße 11
D-35394 Gießen
service@inline-info.com
Date: February 2024
CONTENT OF DELIVERY
• 1x InLine® SATA 6Gb/s Controller with 4 SATA Ports PCI-Express 2.0
• 1x Driver CD
• 1x Instruction manual (German/English)
Check the contents of delivery for completeness. If individual components are mis-
sing, please contact your specialist dealer.
EXPLANATION OF WARNING SYMBOLS AND NOTES
This symbol indicates information that contributes to better
understanding.
This symbol indicates that there are fundamental dangers to the health
of persons.
INTENDED USE
This PCI-Express -I/O card utilises the latest PCI-based peripheral controller chip-
set from MosChip, which means that this card can be installed on any PCI-capable
PC system. Most new motherboards no longer have a conventional serial or parallel
interface. With this card, the end user can equip the computer with serial interfaces
to connect their devices via serial or cables. The card offers better performance
and unrivalled data transfer rates.
General warnings
• Do not open the housing for installation until the power source has been
disconnected.
• Protect from dust and moisture.
If the computer housing is open, live parts can be touched, there is a
risk of electric shock and the installation may have to be carried out by
a specialised company.
NON-INTENDED USE
The following is considered improper use in the sense of foreseeable misuse:
• Install the PCI Express card in the correct slot, otherwise the computer and
card may be damaged.
• Avoid the occurrence of short circuits or bypasses during installation.
FEATURES / SPECIFICATIONS
• PCI-Express 2.0 x1 interface allows a bus bandwidth of up to 5Gb/s
• 4 internal SATA ports for connecting up to 4 SATA devices
• Marvell 88SE9215 chipset
• Compliant with SATA 3.0 specifications, with data rates of 6Gb/s, 3Gb/s and
1.5Gb/s
• Bootable
• Supports NCQ and FIS based port multipliers (Windows only)
• SATA hot-plug function
• System requirements: Windows 11 / 10 / 8.1 / 8 / 7 / Vista / XP / Server
2003/2008/R2 (all 64/32-bit), Linux, MAC OS
2
Before installing and activating the interface card, please ensure that you
have a full backup of your existing data from the hard drive. The manu-
facturer is not responsible for data transfer due to misuse, misapplica-
tion or negligence. If you have an installation problem, please contact your dealer.
HARDWARE INSTALLATION
1. Switch off your computer and all devices connected to it.
2. Remove the computer housing. Refer to your computer's operating instructions
for details.
3. Find an unused PCI Express slot and remove the slot bracket. Save the screw
for later.
4. Align the card horizontally in the PCI slot and insert it firmly and evenly. Take
care not to force it in. As soon as the card is correctly seated in the slot, screw
it to the housing using the screw.
5. Then connect up to four SATA drives to the internal SATA 0 to SATA 3 ports
using optionally available SATA data cables.
6. Close the computer housing.
7. Switch on the computer. Now you can install the driver!
The enclosed driver CD contains all the necessary drivers. For Windows
11, Windows 10, the drivers are downloaded automatically.
Update drivers:
If you have difficulties with the driver CD or your device does not have a drive, you
can find the latest drivers and the latest changes to this document at:
https://www.inline-info.com/downloadcenter
DISPOSAL
Electrical and electronic equipment and batteries must not be disposed of
with household waste. The consumer is legally obliged to return electrical
and electronic equipment and batteries at the end of their service life to the desig-
nated public collection points or to the point of sale.
SIMPLIFIED EC DECLARATION
OF CONFORMITY
The Manufacturer / Importer:
INTOS ELECTRONIC AG
Siemensstrasse 11
35394 Giessen
hereby declares that this InLine® SATA 6Gb/s Controller, complies with all rele-
vant provisions of the EMC (2014/30/EU) and ROHS (2011/65/EU + 2015/863/EU)
directives.
The complete part of the EU Declaration of Conformity is available at
the following internet address:
https://www.inline-info.com/en/downloadcenter
DISCLAIMER
1st edition English 4/2024
Documentation © 2024 INTOS ELECTRONIC AG
All rights reserved. No part of this manual may be reproduced in any form or du-
plicated or processed using electronic, mechanical or chemical processes without
the written consent of the publisher. It is possible that this manual may still contain
typographical errors or misprints. However, the information in this manual is che-
cked regularly and corrections are made in the next edition. We accept no liability
for technical or printing errors and their consequences. All trademarks and indust-
rial property rights are recognised. Changes in the sense of technical progress can
be made without prior notice. Our products, including the packaging, are not toys
and may contain small parts and sharp objects.
Please keep away from children.
