Fig. 1 Binding posts at rear of cabinet.
Dynaudio Sapphire

Accessories

Following accessories are contained in the scope of delivery:
• 8 x Spikes (optional use)
• 8 x Damping Feet (optional use)
• 2 x Cloth grilles, black (detachable)
• 2 x Damping pads for bass reflex port (optional use)
• 1 pair white gloves
• 1 dust cloth

Connecting

Connecting the loudspeakers

1. Connect a two-pole (+/-) loudspeaker cable to the binding posts, located at rear of the
cabinet (see Fig. 1). The high quality, gold plated binding posts can accommodate
different connection systems:
– 4.0 mm banana plugs: The pins can be put directly into the binding post without
any tightening necessary.
– Cable spades: Untighten the binding posts, insert the spade into the opening, and
secure the spade by tightening the posts.
– Bare wires: Untighten the binding posts and place the cable into the binding posts.
Tighten the posts.
