Verkabelung Diagarm; Rvv Ng Anschlussplan / Diagram - Royal Vendors Rvv Ng Serviceanleitung

Verkabelung Diagarm

Y - ENCODER X - ENCODER
1 2 3 4 5 1 2 3 4 5
Y-AXIS X-AXIS
STEPPER STEPPER
MOTOR MOTOR
1 2 3 4 5 6 1 2 3 4 5 6
Y-Achse Startposition
Schalter
NC COM
NO
POSITION VMC CONNECTION DESCRIPTION
P1 INT. / EXT. DEX / REMOTE MODE
P2 SERIAL DISPLAY
P3 SELECTION TOUCHPAD
P4 SOLD OUT INDICATORS
P4A READY TO VEND INDICATORS
P5 POWER / 24 VOLT AC
P6 REFRIG. / ENERGY MANAGEMENT
P7 DR. SWITCHES / ELEC. LOCK / OPTIONS
P8 TEMPERATURE / HEALTH SENSOR
P9 MULTI-DROP BUS
P10 VEND MOTORS
P11 AUSGABE DOOR POWER
P13 BDM
P14 OPTI C AL PRODUCT DELIVERY SENSOR
P15 PARALLEL DISPLAY
SW1 CONTROLLER MODE BUTTON
LED1 DROP SENSOR EINSTELLUNGS L.E.D.
DROP SENSOR EINSTELLUNGS
R117
TRIMPOT
J1 DEX PHONE JACK
Royal Vendors Inc.
Produktaufname Baugruppe
BLACK
P7 P5 P4 P6
BROWN P1
RED
3 2 1 3 2 1 3 2 1 2 1
YELLOW
GREEN
BLUE
GREY
WHI T E
P2
P3
PINK
2 1 2 1
WHT
RED
WHT
RED
PLUNGER DRIVER
M O T O R
MOTO R
TACH
P1
VCC
OUT
GND
3 2 1
HALL
RCVR
BOARD EFFECT
SENSOR
X-AXIS CABLE CHAIN
P 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 1 2 3 4 5 6 7 8 9 10 11 12
P1
5V
DC
DMC Platine
GREEN
R E D
BLACK
BROWN
WHITE
24V
DC
P6
P9
POSITION DMC CONNECTION DESCRIPTION
P1 Y-HOME SWITCH / Y-MTR / Y-ENCODER
P2 X-MTR / X-ENCODER
P3 DELIVERY AUFNAHMER BOARD (P1)
P DELI V ERY D00R SWI T CH / DETECTOR
4
BOARD / AUSGABE POWER (VMC-
P11)
P6 VMC MDB (P9) / BILL VALIDATOR
Service Anleitung und Ersatzteil Katalog
Altere Version
4 LED
AUSGABE
OPTICS
Innere Ausgabe
Türschalter
P1
XMTR
NC
BOARD RED
NO
COM BLACK
1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6
P3 P4
5V 5V 5V
DC DC DC
DELIVERY ASSY DESCRIPTION
POSITION
P1
X-AXIS (DMC-P3)
P2 DRIVER MOTOR
P3 PLUNGER MOTOR
P4 HALL EFFECT SENSOR (POSITION)
P5 HALL EFFECT SENSOR (TACHOMETER)
P6 XMTR BOARD
P7 RCVR BOARD
DELIVERY
1
DETECTOR
1
JP1
ELECTRONIC
DOOR LOCK (P7)
Otional
1 2 3 4 5 6 7 8 9 10 11 1 2
P5
BATTERY BACKUP
PHONEJACK LOCATED
IN VEND AUSGABE
RED
BLK
Türschalter
OBEN
Türschalter
UNTEN
1 2 3 4 5 6
MDB
Wechsler
VALI D ATOR
DELIVERY
JP1
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
Otional
DOOR LOCK
RECEPTACLE
CABINET SIDE
+
RED
BLK
NC
BLACK
NO
RED
COM
NC
NO
COM RED
MANUAL
OVERRIDE
SWITCH
HEALTH
COLOR
SAFETY
BLUE
SENSOR
COLOR TEMP
SENSOR
NATURAL
92
