Mounting instructions for waterpipe installers:
Important: Read these instructions thoroughly before installing
the appliance. Determine the precise position in the salon with
the salon owner and the installation specialist.
Caution:
The wash unit is intended for operation in clean and
dry rooms at normal room temperature.
In the water supply system only original components
supplied by the manufacturer must be used.
The house installation must be equipped with a pressure
reducing valve. Recommended water pressure for the
shampoo station: approx. 3 – 5 bar.
The new set of hoses supplied with the unit must be
used. Old hoses must not be used.
Observe minimum power socket spacing specified in
DIN VDE 0100 and VDE 0100 Part 701.
Ensure that the height of the drain and installation
tunnel is correct.
1.
We recommend to provide the supply lines with a
central shut-off device.
If the system is operated without a suitable shut-off
device, the angle valves must be closed at the end
of business hours.
2.
Install the supply water and waste water lines as shown in
Fig. 3.
Mounting instructions for appliance fitters:
3.
Detach the backrest cushion (1): (Fig. 1)
Pull the backrest upwards and remove.
4.
Detach the seat body (2): (Fig. 1)
Only slacken the 4 wing screws (3) underneath the seat.
Remove the 2 hexagon socket bolts (4) (connection
between seat and frame). Detach the element connecting
the seat to the leg rest (6). Pull the seat together with the
armrests upwards.
5.
Prepare the cover section for connection of the installation
shaft: (Fig. 1 + 2)
Make sure that the mounting side corresponds to that
shown in the installation diagram!
Make 1 drilling Ø 80 mm and 3 drillings Ø 5,5 mm for
mounting brackets.
6.
Align the substructure (9) according to the installation
template and secure to the floor.
6 anchor bolts M 10 x 125 (extending 30 mm
above the finished floor) or metal plugs with metric
thread for hexagonal screws M 10 x 60.
7.
Secure the side cover sections (7) to the unit using Velcro
tape. Attach 2 mounting brackets for the installation tunnel
to both the side section (Fig. 2) and wall (Fig. 3): Fasten
the mounting brackets on the top and front using M5
screws + washers + nuts, fasten mounting brackets on the
rear only after the water installation.
Pure Edition MO W+R
GB
Mounting instructions for waterpipe installers:
8.
Make sure that pipes/pressure hoses are parallel. Connect the
unit. Fit 40 mm dia. waste water pipe and R ½" pressure lines
with stop taps between the wall and unit. Prevent the stop
valves from turning while they are being screwed on.
Connect the waste water hose to the siphon using a seal and
union nut. Insert the waste water hose at least 3 to 4 cm into
the siphon. Connect the drain
bushing to the waste water hose using a hose clamp.
9.
Close the mixing tap. Open the stop valve and check for leaks
with the mixing tap closed. Check the mixed water. The hot
water and cold water supply must correspond to the coloured
symbols on the mixing
tap.
10.
Check the pressure of the unit with 8 bar water pressure. Then
set the pressure to 3 to 5 bar. On completion of the installation
work, always rinse out the water pipes. A central regulating tap
is required if more than one unit is installed. This tap must be
easily accessible from the salon.
These mounting instructions apply to the connection
of one unit. If more than one unit is to be installed, the pipe
cross section must be increased accordingly.
Important: If the water pressure is above 5 bar, it must be
regulated by a pressure reduction valve.
Note for salon owners:
The connections described under points 1 to 2 and 8 to 10 must be
performed by the installer. The installer is responsible for any
problems that may occur. The manufacturer of the unit shall not
accept warranty claims for this work.
Mounting instructions for electricians:
11.
Electrical connection / mounting installation shaft:
Caution:
Electrical connections are reserved to
authorized electricans!
The safety regulations of the hairdressing trade must be
observed. Installation and operation must be in accordance with
the norm IEC 60364 ...
During assembly work the complete system must be
isolated from the power supply and secured against
unintended switch-on!
In the wash unit, use only the plug-in connectors supplied with
the appliance and specified in the mounting instructions!
