AZZA Hurricane III Digital RGB Fan Installation
1
3
Digital RGB
WARNING!
The addressable RGB fans can connect directly to the 5V addressable headers of compatible
motherboard, such as those from MSI, ASUS Gigabyte and ASROCK.
Please note: Only 5V addressable header from compatible motherboard are supported,
please do Not connect the fan to a 12V non-addressable header.
Please check your motherboard's specifications before use. Do not go past the
motherboard's allowed limits on power ratings and LED count when connecting multiple fans
/ LED strips.
RGB 1, RGB2
+12V
R
RGB1
Expanse
Connector
15
2
4
RGB Motherboard
SYS_FAN
Digital RGB
G
B
