Universal Input KNX-S
6
Commissioning
Programming the physical address and application program
￭
Switch on the bus voltage.
￭
Press the programming button (2).
The programming LED (3) lights up.
￭
Program the physical address with the ETS.
The programming LED goes out.
￭
Program the application program with the ETS.
6.1
Safe-state mode and master reset
Safe-state mode
The safe-state mode stops the execution of the loaded application program.
Only the system software of the device is still functional. ETS diagnosis func-
tions and programming of the device are possible.
Activating safe-state mode
￭
Switch off the bus voltage or remove the KNX device connection terminal.
￭
Wait approx. 10 seconds.
￭
Press and hold down the programming button.
￭
Switch on the bus voltage or attach the KNX device connection terminal.
￭
Wait until the programming LED flashes slowly.
￭
Release the programming button.
The safe-state mode is activated.
82407708
Figure 6: Connection example with outputs switched in parallel
8 / 10
23.01.2024
