Olymp LavaSit PURE Edition Montageanleitung Seite 7

Mounting instructions for electricians:
13. Electrical connection:
Caution:
• Electrical connections are reserved to
authorized electricans!
•
The safety regulations of the hairdressing trade must be
observed. Installation and operation must be in
accordance with the norm IEC 60364 ...
•
During assembly work the complete system
must be isolated from the power supply and
secured against unintended switch-on!
•
In the wash unit, use only the plug-in connectors
supplied with the appliance and specified in the
mounting instructions!
•
Cables must be so arranged that they are not in the
vicinity or moving parts! Damage or crushing must thus
be prevented!
•
For reasons of mechanical security as well as the
electromagnetic compatibility no cable excess may be
stowed away in the shampoo unit.
Shampoo station with direct connection:
•
The shampoo station must be connected to the
electrical floor outlet by a qualified electrician.
•
Unit with direct connection: shorten the connection
cable and connect it to the floor outlet with less
cable excess.
Mounting instructions for appliance fitters:
Shampoo station with mains cable:
•
The shampoo station is „ready to plug in" and can be
plugged to a wall plug socket by the customer without
the help of an electrician.
•
The power supply cable from the unit must be
arranged so that it is not jammed between the
unit frame and the floor!
•
Do not place any plug socket inside of the unit!
Always route the mains cable outside and plug into a
customer's site plug socket.
•
The wash unit with power supply cable must not be
connected to the power supply using an extension
cable.
•
Arrange the power supply cable so that the plug is
easily accessible and can be isolated from the wall
socket.
•
In case several wash units are to be installed in-line,
the power supply cable must not be connected via
further units.
Mounting instructions for electricians:
13.1 Direct connected variant: (Fig. 5)
Caution: this type of connection must only be
made by a qualified electrician!
> Connect the mains cable from floor to the
supplied system socket (Fig. 3).
> Insert system socket into the system connector and
close locking clip (Fig. 4).
Pure Edition MO B+R
GB
Mounting instructions for electricians and
appliance fitters:
Variants for single units:
13.2 Mains cable variant: (Fig. 6)
appliance fitters:
> Route the mains plug to the outside.
Variants for in-line installation:
13.3 Primary in-line unit with direct connection
+ secondary in-line unit: (Fig. 7)
electricians:
> Connection of primary in-line unit – see 13.1
appliance fitters:
> Connection of secondary in-line unit:
Route the distribution cable from the primary
in-line unit through the installation shaft and
connect to the secondary in-line unit: To do so,
detach the control box from the substructure
(Velcro fastening), insert the system socket of the
distribution cable into the control box and secure
with the screw. Reattach the control box to the
substructure.
13.4 Primary in-line unit with mains cable
+ secondary in-line unit: (Fig. 8)
appliance fitters:
> Connection of primary in-line unit – see 13.2
> Connection of secondary in-line unit – see 13.3
Mounting instructions for appliance fitters:
14. Only for in-line installation: (Fig. 2):
Provide the installation tunnel (1) with rubber edge
protection (2) on both sides and put it onto mounting
brackets; to do this, push the tunnel diagonally onto the
mounting brackets from the rear and then align it
vertically.
Fasten the mounting bracket on the rear of the tunnel
from the bottom of the tunnel onto the shampoo station.
15. Assembly: (Fig. 1)
Attach the seat body (2) to the frame and secure the seat
and frame using the 2 hexagon socket bolts (4).
Tighten the 4 wing screws (3) underneath the seat.
Secure the cover sections (7) to the frame (9) using Velcro
tape.
Loosely bind the 2 pressure hoses (hot + cold) and drain
hose together using cable ties.
Caution: The 3 hoses must not touch the frame (9) at any
point.
Secure the rear cover section (8) to the frame (9) using
the 6 plastic screws.
Attach the element connecting the seat to the leg rest (6)
and fit the backrest cushion (1).
