V-TAC VT-8141 Installationsanleitung

DIY
WORK MODES
TECHNICAL DATA
Model
Wa�s
Lumens
Beam Angle
Body Type
Dimension
Ba�ery
Charging Time
Working Time
Sensor Mode
Detec�on Angle
Detec�on Distance
Delay Time
Input Voltage
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future reference.
If you have any another query, please contact our dealer or local vendor from whom you have
purchased the product. They are trained and ready to serve you at the best. The warranty is valid for
2 years from the date of purchase. The warranty does not apply to damage caused by incorrect
installation or abnormal wear and tear. The company gives no warranty against damage to any
surface due to incorrect removal and installation of the product. The products are suitable for 10-12
Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is
warranted for manufacturing defects only.
INSTALLATION INSTRUCTION
LED CABINET LIGHT
WITH PIR SENSOR
VT-8141
1.5W
110lm
180°
Aluminum
300*40*11mm
LITHIUM 1500mA
4 Hours
5~6 Hours
PIR Sensor
120°
3M~5M
15s
DC: 5V, 1A
VT-8142
2W
160lm
180°
Aluminum
400*40*11mm
LITHIUM 2200mA
6Hours
6~7 Hours
PIR Sensor
120°
3M~5M
15s
DC: 5V, 1A
VT-8143
2.5W
260lm
180°
Aluminum
600*40*11mm
LITHIUM 3000mA
7 Hours
7~8 Hours
PIR Sensor
120°
3M~5M
15s
DC: 5V, 1A
