Quality audio
HHA762402
TECHNICAL PARAMETERS:
Output Power:
Speaker Unit:
Sensitivity:
Frequency Range:
Signal-to-Noise Ratio (SNR):
FEATURES:
·Remote Control
·3.5mm Audio Input
·USB
ELECTRICAL SPECIFICATIONS:
Power Supply:
Remote Control:
OPERATING INSTRUCTIONS
LED indicator
Indicator Status
White AUX
White OPTICAL
White BLUETOOTH
White HDMI(ARC)
White USB
REAR PANEL
1. External subwoofer output interface
2. Optical digital audio input interface
3. AUX input interface
4. HDMI(ARC) input interface
5. Surround sound sr output interface
6. Surround sound sl output interface
SIDE PANEL
1. On/Off/Mode
2. Play/Pause
3. Next/Increase Volume
4. Prev/Decrease Volume
5. 1G-32G USB input interface
OPTICAL INPUT:
1. Connect one end of the optical audio connecting cable to the optical output
interface, and the other end to the optical input interface of the unit.
2. Press the Sound Source Switching key repeatedly or the Optical key on the
remote control to switch to Optical mode, after which the white indicator will
light up or show OPT.
optical audio connecting cable is required (not included).
KEEP THIS INSTRUCTION MANUAL FOR REFERENCE AS IT CONTAINS IM-
PORTANT INFORMATION.
NL / EN - support@alleenonline.nl
BE / FR - support@alleenonline.be
30W(Front), 30W(Center),
25W (Surround), 40W (Subwoofer)
2.25" x 6 (Main Unit), 6.5" x 1 (Subwoofer)
>60dB
50Hz - 16kHz
>80dB
·Optical Audio Input
·Bluetooth
·HDMI (ARC) Input
100-240V AC 50/60Hz 0.4A
1.5V DC 2 x "AAA" Batteries (NOT INCLUDED)
Remote control
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. SW +,-
11. EQ_News
12. Mode
13. EQ_Movie
14. Next
15. Volume +
16. Mute
USB:
1. Insert the USB into the USB interface.
2. Press the Sound Source Switching key repeatedly or the USB key on the
remote control to switch to USB mode.
3. Ensure that your USB is stored with MP3 audio.
4. USB devices must be operated with the remote control for functions like
Pause/Play, Previous/Next Track.
5. Replay: Replay a single track by pressing the replay key once or all tracks by
pressing the replay key twice.
HDMI(ARC) INPUT:
1. Connect one end of the HDMI(ARC) audio connecting cable to the HDMI input
interface, and the other end to the HDMI input interface on the unit.
2. Press the Sound Source Switching key repeatedly or the HDMI(ARC) key on
the remote control to switch to HDMI mode, after which the white indicator
will light up or show ARC.
3. Ensure that the audio setting of the sound source is set to HDMI.
AUX IN:
1. Connect one end of the 3.5mm audio connecting cable to the audio output
interface and the other end to the 3.5 LINE input interface of the unit.
2. Press the Sound Source Switching key repeatedly or the LINE key on the
On/Off
remote control to switch to AUX mode, after which the white indicator will
Play/Pause
light up or show AUX.
Prev
Volume - 3. Ensure that the audio setting of the source is in "Connecting to Sound
EQ Music
Equipment" status.
Repeat
Cen +, -
BLUETOOTH:
Front +,-
Rear +,-
1. Press the Sound Source Switching key repeatedly, or the Bluetooth key on the
remote control to switch to Bluetooth mode, after which the white indicator
will blink bt.
2. Turn on Bluetooth on your device and search for "Hyundai Dynasty 5.1" Once
found, click on it to pair. If the pairing is successful, the white indicator bt
will turn solid.
3. Note that the unit will automatically connect to this device (after a successful
connection) in the future as long as the Bluetooth setting is turned on on both
the unit and the device.
TROUBLESHOOTING:
• No Power Supply: Check whether the small plug of the source adapter is
connected to the main unit or whether the power source plug is connected.
• No Sound: Check whether the volume is turned to the minimum. Check
whether the mute key is turned on.
• Remote Control Not Working: Check whether the battery power is low; if yes,
replace the battery. Check whether the remote control receiver on the main
unit is obstructed.
• No Sound When Bluetooth is Connected for the First Time: Check whether
Bluetooth is paired with the unit.
• If the problem persists even after checking the above points, please contact a
qualified technician for further assistance.
