Original operating instruction - GOJAK 4520
Individual parts
10
18
16
Nr.
Article number
411300
1
2
411301
411302
3
411304
4
411305
5
411306
6
7
411307
411308
8
9
411338
411310
10
Specifications
Material: Steel, partially galvanised
Weight [kg]: 19,0
Dimensions W x H x L [mm]: 640 x 185 x 635
GoJak wheel ø [mm]: 73
Permissible tyre width [mm]: up to 510
Technically permissible load capacity [kg]: 510
Technically permissible speed [km/h]: 10
7
6
2
10
17
9
Name
Locking claw
Lower pivot pin
Pedal spring RIGHT
Disc
Split pin
Spring for switch lever
Screw with washer
Switch lever
Wheel 3'' incl. Bearings/Nut
Wheel fastening nut
8
1
14
15
4
3
4
5
9
Nr.
Article number
11
411313
12
411314
13
411315
14
411316
15
411317
16
411339
17
411329
18
411330
19
411321
20
411323
20
12
11
13
19
10
9
Name
Working claw
Spring for working claw
Upper pivot pin
Bracket for stop disc
Stop disc
Steel roller drum
Roller bearing
Screw
Pedal lock right
Pedal
