English
Removable Fan Installation Guide
To Remove the Fan
A. Press the tab located below the fan A. Press the tab located below the fan
upward.
To Install the Fan
A. Slant the fan and match the hooks
to the fan mounting hole.
06
eSATA
USB 3.0
B. Detach the fan by lifting the fan
up from the tab.
\ Click! /
B. Press down the fan until it is seated
correctly with a "Click" sound.
eSATA Port
USB 3.0 Port
